PFS3211-8GT
Opis
Przełącznik 11-portowy • 8x RJ45 10/100/1000M (Hi-PoE/PoE+/PoE); • 1x RJ45 10/100/1000M; • 2x SFP 1000M; • Zasilanie: DC 48 ~ 57V • PoE budget: 120W • Wymiary: 150 x100 x42 mm...
Gwarancja: 36 mies.
Uwaga! Produkt wycofany z produkcji!
Karta katalogowa
Tekstowa zawartość karty katalogowej PDF:
DH-PFS3211-8GT
www.dahuasecurity.com
Features
· Layer 2 Hardened Ethernet switch
· MAC auto study and aging, MAC address list capacity is 4K
· Conform IEEE802.3, IEEE802.3u, IEEE802.3ab/z and
IEEE802.3X standards
· Adopts metal structure
· Industrial wide working temperature design: -30°C~+65°C
· High protection grade, supports common mode 4KV,
differential mode 2KV
· Supports dual power backup
DH-PFS3211-8GT
11-Port Gigabit Switch (Unmanaged)
Technical Specification
ModelDH-PFS3211-8GT
Ethernet Port
9*10/100/1000 Mbps Base-T
2*1000Mbps Base-X
Switching Capacity33Gbps
Packet Forwarding Rate16.37Mpps
Packet Buffer Memory1.75Mb
MAC Table Size4K
Flow ControlEnable by default
Application Humidity10%~90%
PowerDC9~57V
Lightning Protection
Common Mode 4KV
Differential Mode 2KV
ESD
Contact discharge: ±6kV
Air discharge: ±8kV
Working Temperature-30°C~65°C
Weight0.62kg
Dimension(WxDxH)150mmx110mmx42mm
Accessories
Model
PFT39501.25G 850nm,500m,LC, Multi-mode
PFT39601.25G 1310/1550nm,20km,LC, Single-mode
PFT39701.25G 1550/1310nm,20km,LC, Single-mode
Product Overview
DH-PFS3211-8GT is a layer two Hardened Switch, which provides 9
*10/100/1000Mbps Ethernet ports, 2 *1000Mbps optical ports. With
high level lightning protection and wide working temperature range
makes it a better performance in outdoor or harsh environment.
