PFS3008-8GT-96
Opis
Przełącznik 8-portowy niezarządzalny • 8 x10/100/1000M Base-T（zasilanie PoE） • Port 1 ≤ 60 W, port 2-8 ≤30 W, załkowicie l≤ 96 W • IEEE802.3af/IEEE802.3at/Hi-PoE • Zasilanie: DC48 ~ 57V • Wymiary: 190×100×30 mm • Waga: 480 g...
Gwarancja: 36 mies.
Karta katalogowa
Tekstowa zawartość karty katalogowej PDF:
PFS3008-8GT-96
Product Overview
PFS3008-8GT-96 is a 8-port Gigabit Ethernet switch, which provides
8*10/100/1000Mbps PoE port and supports Hi-PoE power supply.
www.dahuasecurity.com
Features
· Layer two commercial switch
· Supports IEEE802.3, IEEE802.3u and IEEE802.3X standards
· MAC auto learning, aging, MAC address capacity is 2K
· Supports MDI/MDIX self-adaptation
· RJ45 port supports 10/100/1000 Mbps self-adaptation
· Supports IEEE802.3af and IEEE803.3at power supply
standards
· Adopts metal enclosure
· Supports Hi-PoE 60W
· Supports DC 48-57V power supply
PFS3008-8GT-96
8-Port Gigabit Ethernet PoE Switch
Technical Specification
ModelPFS3008-8GT-96
Ethernet Port
8*10/100/1000Mbps PoE ports
PoE Power ConsumptionPort1≤60W, Port2-8≤30W, Total≤96W
PoE ProtocolIEEE802.3af (PoE), IEEE802.3at (PoE+), Hi-PoE
Switching Capacity20Gbps
Packet Forwarding Rate11.9Mpps
Packet Buffer Memory1.5Mb
MAC Table Size8K
Flow ControlEnable by default
Application Humidity10%~90%
PowerDC48~57V power adapter
Lightning Protection
Common Mode 2KV
Differential Mode 0.5KV
Working Temperature-10°C~+55°C
Weight0.49kg
Dimension(WxDxH)190mmx100mmx30mm
