ITC237-PW1B-IRZ
Opis
Kamera IP do identyfikacji tablic z serii ULTRA LPR, 1/2,8" 2 Mpx CMOS, obiektyw motozoom 2,7 - 12 mm, True WDR, IR LED, Zasięg IR 3-8 m, Vmax. pojazdu: < 60 km/h), wejście/wyście alarmowe 1/1, funkcje: biała/czarna lista, przekroczenie bariery, detekcja pętli indukcyjnej, rejestracja na karcie pamięci micro SD, CGI, przeszukiwanie archiwum z pioziomu przeglądarki internetowej...
Gwarancja: 36 mies.
Uwaga! Produkt wycofany z produkcji!
Karta katalogowa
Tekstowa zawartość karty katalogowej PDF:
WDR Access ANPR | ITC237-PW1B-IRZ
Series P67 Temperature IR 500m
8KProteV
Lightning
Wiper IK10 IVS Auto Tracking
ITC237-PW1B-IRZ
2 Megapixel Full HD WDR Access ANPR Camera
System Overview
Featuring a True Day/Night, 2-megapixel resolution LPR camera in
parking and access control environement, video detect and
recognize the plate in low speed less than 20kmh (for Australia and
New Zealand) with embedded LPR algorithm. White list database
inside the camera control the barrier opened. This model provides
true WDR for environment with direct sunlight or glare,even head
light on when the vehicle approach.
Functions
Embedded license plate recognition algorithm
With built-in intelligent video analytics, the camera has the ability to
detect and recognize moving vehicle's plate number within low
speed. No matter for the approaching or departure vehicle, access
ANPR camera will take a snapshot for plate cutout, vehicle
overview picture and also record the surveillance video.
Wide Dynamic Range
Embeded with industry leading wide dynamic range (WDR) technology,
vivid plate picutures are achieved even in the most intense contrast
lighting conditions. For applications with both bright and low lighting
conditions that change quickly or the head light of vehicle is on at night,
True WDR (140dB) optimizes both the bright and dark areas of a scene at
the same time to provide usable video of plate.
Embedded White List
Embeded with white list inside the camera, control the barrier
opened by the camera relayout if the plate number recognized is in
the white list.Support to import batch list as much as 10000 records.
Multiple Detection
The camera supports loop and video detection, it is more stable when the
system is used for controlling the barrier or counting the vehicle number
in the access control, also even the loop detection is accident, video
detection will be instead automatically.
Environmentel
With a temperature range of -40 °C to +60 °C, the camera is designed for
extreme temperature environments. Subjected and certified to rigorous
dust and water immersion tests, the IP67 rating makes it suitable for
demanding outdoor applications. For enviorments with rain, sleet, snow
and fog, an integrated wiper provides users with clear visibility at all
times.
www.dahuasecurity.com
·Embedded with LPR algorithm inside the camera.
·Support plate cutout, overview picture snapshot and
video recording
·Embedded with White list database,control the barrier
·Powerful 2.7-12mm motorized lens and IR light, ideal
for monitor ANPR distance as 3~8m
·Wide working temparature, IP67, IK10 and superior
performance for outdoor applications·
·True WDR technology
Access ANPR | ITC237-PW1B-IRZ
Technical Specification
www.dahuasecurity.com
DH-PFB303W
Wall mount
Camera
Image Sensor 1/2.8” 2Megapixel Starvis R CMOS
Effective Pixels 1920(H) x 1080(V)
Scanning System Progressive
Minimum Illumination 0. 005Lux/F1.6 (Color),0Lux/F1.53(IR on)
Electronic Shutter Speed 1/50~1/10000
IR Distance 3~8m
IR LEDs 4
Lens
Lens Type Motorized/ Auto Iris(DC)
Mount Type Board-in Type
Focal Length 2.7mm~12mm
Max Aperture F1.6
Angle of View H: 101˚~ 36 ˚ V:53 ˚ ~20 ˚
Focus Control Auto
Focus Distance Range 3-8m
Focus width Range 1 lane
Intelligence
LPR function Embedded with lpr engine in the camera
Detection model Loop or video detection
Snapshot Overview and cutout of plate for picture
OSD overlay Time, place,plate number,lane No
White list 10000 records database inside the camera
Barrier control 1 ch relay out to control the barrier
Video
Compression H.265/H.264M/H.264H/H.264B
Resolution 1080P(1920x1080) / 720P(1280x720) / D1(704x576)
Frame Rate
Main Stream: 1080P(1 ~ 25/30fps)
Sub Stream: 720P/ D1 (1 ~ 25/30fps)
Bit Rate Control CBR VBR
Bit Rate
32 ~ 16384 Kbps
Day/Night Auto(ICR) / Color / B/W
BLC Mode BLC,HLC,WDR(140db)
Dual Stream Support, Main stream and sub stream
White Balance Auto/Manual
Gain Control Auto/Manual
Noise Reduction 3D
Network
Ethernet RJ-45 (100/1000Base-T)
Protocol IPv4/IPv6, HTTP, TCP/IP, UDP, NTP, DHCP, DNS,
Interoperability CGI, Onvif
Max. User Access 20
Edge Storage
Micro SD, Max 64GB Status Display Local PC for
Instant Recording
Web Viewer IE9,IE10,IE11, Chrome V33, V41
Management
Software
DSS, PMS
Certifications
Certifications
CE
FCC
Access ANPR | ITC237-PW1B-IRZ
Accessories
Pole Mount:
Environmental
Ingress Protection &
Vandal Resistance
Construction
Net Weight
Ordering Information
Dimensions (mm/inch)
Rev 001.001 © 2016 Dahua . All rights reserved.
®
www.dahuasecurity.com
Type Part Number Description
2MP Camera
ITC237-PW1B-IRZ
2MP HD Access LPR, loop
and video detection,embedded
LPR
Accessories
PFA162 Housing Bracket
1.2m Pole 1.2m Pole
PFA162
House Bracket 1.2m Pole
Interface
Audio Interface Input/Output 1 Input / 1 Output
RS485 NA
Alarm 2/1 channel In/Out
Eelectrical
Power Supply DC12V, PoE (802.3af)
Power Consumption <12W (with IR on, motorized lens working)
Environmental
Operating Conditions -40°C~+60°C, Less than 95% RH
Ingress Protection &
Vandal Resistance
IP67, IK10
Construction
Dimensions 273.30mm x 94.8mmx 94.8mm
Net Weight 1.12kg( 1.52 kg with packaging)
