GV-LPR/4-NVR

Dostępność: 0
Cena: 7 596,37 zł 7596.37 (1 623,64 €)
bez 23.00% VAT i kosztów dostawy
ilość szt.

towar niedostępny

dodaj do przechowalni
Producent: GEOVISION
Kod produktu: 55-LPRPT-004

Opis

Klucz licencyjny umożliwiający włączenie w systemie nadzoru wizyjnego funkcji identyfikacji tablic rejestracyjnych dla 4 kamer...

Gwarancja: 36 mies.

Karta katalogowa PDF


Tekstowa zawartość karty katalogowej PDF:

Introduction
GeoVision's License Plate Recognition is an effective and low ‐maintenance solution to ensure the security of parking lots, which are
prone to crimes due to isolated and unstaffed corners. In addition to providing high ‐resolution video monitoring and recording, the
LPR solution detects and recognizes vehicle license plates upon motion or I/O trigger.

A GV ‐ LPR1200, GV ‐ DSP LPR, GV ‐DVR LPR or GV ‐VMS LPR recognizes license plates detected in the video source, and sends the LPR
results to GV ‐ASManager. Access can be granted when the detected license plate numbers match the vehicle registered in
GV ‐ASManager's database. Alarm notif ications and playing back LPR results are also supported.


License Plate Recognition February 7, 2018
-1-


Available Version

Argentina Australia Austria Belgium

Brazil Canada China Chile

Columbia Croatia Czech Republic France

Germany Hungary India Ireland

Israel Italy Morocco Mexico

Norway Poland Portugal Qatar

Russia Slovakia South Africa Spain

Taiwan UK USA Vietnam
There is a Global version which is suitable for most of the other countries. More are to be implemented.

Features
GV ‐ASManager Access Control System
* Control up to 255 GV ‐DVR LPR / GV ‐ VMS LPR / GV ‐ DSP LPR / GV ‐LPR1200
* Up to 8 recognition channels per GV ‐ DVR LPR / GV ‐VMS LPR
* Up to 100,000 vehicles
* Up to 100 Web browser connections
* Mu ltiple vehicles per user
* Import / export of vehicle data in Access or Excel file format
* Vehicle hotlist to help locate stolen vehicles or other vehicles of interest
* Parking lot management to control vehicle access, maximum stay time allowed and number of vehicles allowed
* GV ‐Access mobile ap plications to remotely open LPR lanes
* GV ‐ASWeb: Remotely enroll vehicles and set up GV ‐ DVR LPR / GV ‐ VMS LPR / GV ‐ DSP LPR / GV ‐LPR1200 on GV ‐ASManager
* GV ‐ASWeb: Remotely search detected vehicles, see license plate snapshots, watch recordings from connected GV ‐ DVR LPR /
GV ‐ VMS LPR / GV ‐ DSP LPR / GV ‐ LPR1200
* Languages supported: English, French, Hebrew, Japanese, Portuguese, Russian, Serbian, Spanish, Traditional Chinese, Turkish




License Plate Recognition February 7, 2018
-2-

License Plate Recognition February 7, 2018
-3-

System Requirements
GV ‐ASManager
The following are minimum system requirements to run GV ‐ ASManager.
32‐bit
Windows 7 / 8 / 8.1 / 10 / Server 2008
OS
64‐bit
Windows 7 / 8 / 8.1 / 10 / Server 2008 R2 / Server 2012 R2
CPU Core 2 Duo E8400, 3.0 GHz

Memory 2 x 1 GB Dual Channels

Hard Disk 500 GB

VGA PCI ‐Express, 1280 x 1024 , 32‐bit color and support DirectX 10

DirectX End ‐ User Runtimes (November 2008)

Software
.NET Framework 3.5
SQL Server 2005 Express (optional)

Browser Internet Explorer 9.0 or later

Note : GV ‐ASManager has ended support for Windows XP and Vista .

GV ‐ DVR LPR
Number of LPR Channels 1 ‐ 4 Channels
5 ‐ 8 Channels
OS
64‐bit Windows 7 / 8 / 8.1 / 10 / Server 2008 R2 / Server 2012 R2
1.3 M Core i5 2400, 3.1 GHz Core i7 2600, 3.4 GHz
CPU
2 M Core i7 4770, 3.4 GHz Core i7 6700, 3.4 GHz
Memory 2 x 2 GB Dual Channels
Hard Disk 500 GB

VGA PCI ‐Express, 1280 x 1024 , 32‐bit color and support DirectX 10

DirectX End ‐ User Runtimes (November 2008)

GV ‐ DVR / NVR
GV ‐ASManager 4.2.1 ‐ 4.2.3: V8.5.9.0
GV ‐ASManager 4.3: V8.6.0.0
GV ‐ASManager 4.3.5 ‐ 4.4: V8.6.2.0
GV ‐ASManager 4.4.1: V8.6.2.0 or V8.7.0.0
GV ‐ASManager 4.4.2: V8.7.0.0 or V8.7.1.0
GV ‐ASManager 4.4.3: V8.7.1.0
GV ‐ASManager 5.0: V8.7.1.0
GV ‐ASManager 5.0.1.0 – 5.0.2.0: V8.7.3.0

Hardware External or internal GV ‐ LPR Capture Dongle

Note:
1. It is recommended to use separate PCs for GV ‐ASManager and GV ‐DVR LPR.
2. If no LPR dongle is inserted, license plates will be captured but the plate numbers will not be recognized.
3. The above system requirements were determined with a bit rate of 2 Mbits for 1.3 MP res olution and 2 MP resolution.



GV ‐ VMS LPR (for 32 CH)
Number of LPR Channels 1 ‐ 4 Channels
5 ‐ 8 Channels
OS
64‐bit Windows 7 / 8 / 8.1 / 10 / Server 2008 R2 / Server 2012 R2
1.3 MP
CPU
2 MP
Core i7 3770, 3.4 GHz Core i7 4770, 3.4 GHz
Memory 2 x 2 GB Dual Channels
Hard Disk 500 GB

VGA PCI ‐Express, 1280 x 1024 , 32‐bit color and support DirectX 10

DirectX End ‐ User Runtimes (November 2008)

GV ‐ VMS
GV ‐ASManager 4.3.5 ‐ 4.4.1: V15.10
GV ‐ASManager 4.4.2: V15.10 or V15.11
GV ‐ASManager 4.4.3: V15.11.3
GV ‐ASManager 5.0: V16.11.0.0
GV ‐ASManager 5.0.1.0 – 5.0.2.0: V16.11.0.0

Hardware External or internal GV ‐ LPR Capture Dongle

Note:
1. It is recommended to use separate PCs for GV ‐ASManager and GV ‐VMS LPR.
2. If no LPR dongle is inserted, license plates will be captured but the plate numbers will not be recognized.


License Plate Recognition February 7, 2018
-4-
3. The above system requirements were determined with a bit rate of 2 Mbits for 1.3 MP resolution and 2 MP resolution.


GV ‐ VMS LPR (for 64 CH)
Number of LPR Channels 1 ‐ 4 Channels
5 ‐ 8 Channels
OS
64‐bit Windows 7 / 8 / 8.1 / 10 / Server 2008 R2 / Server 2012 R2
1.3 MP
Core i7 6770, 3.4 GHz
(Only 2 Lanes)
CPU
2 MP
Core i7 6770, 3.4 GHz
(Only 1 Lane)
N/A
Memory 2 x 2 GB Dual Channels
Hard Disk 500 GB

VGA PCI ‐Express, 1280 x 1024 , 32‐bit color and support DirectX 10

DirectX End ‐ User Runtimes (November 2008)

GV ‐ VMS
GV ‐ASManager 4.3.5 ‐ 4.4.1: V15.10
GV ‐ASManager 4.4.2: V15.10 or V15.11
GV ‐ASManager 4.4.3: V15.11.3
GV ‐ASManager 5.0: V16.11.0.0
GV ‐ASManager 5.0.1.0 – 5.0.2.0: V16.11.0.0

Hardware External or internal GV ‐ LPR Capture Dongle

Note:
1. It is recommended to use separate PCs for GV ‐ASManager and GV ‐VMS LPR.
2. If no LPR dongle is inserted, license plates will be captured but the plate numbers will not be recognized.
3. The above system requirements were determined with a bit rate of 2 Mbits for 1.3 MP res olution and 2 MP resolution.


Software License
Free License N/A

Maximum License 8 channels

Increment for Each License 1 channels

Dongle Type Internal or external

Optional Combinations
1. LPR
2. GV ‐ VMS + LPR (1 to 8 license)
3. GV ‐NVR + LPR (1 to 8 license)
4. GV ‐ DVR + LPR (1 to 8 license)


GV ‐ DS P LPR and GV ‐ L PR1200
GV ‐ASManager V4.2.1 – 4.2.2 is only compatible with GV ‐DSP LPR firmware V2.0.3.
GV ‐ASManager V4.2.3 is only compatible with GV ‐ DSP LPR firmware V2.0.4.
GV ‐ASManager V4.3 – 4.3.5 is only compatible with GV ‐ DSP LPR firmware V2.10 and GV ‐LPR1200 V1.01.
GV ‐ASManager V4.4 – 4.4.3 is only comp atible with GV ‐ DSP LPR firmware V2.20 and GV ‐LPR1200 V1.1.
GV ‐ASManager V5.0 – 5.0.2.0 is only compatible with GV ‐DSP LPR firmware V2.30 and GV ‐ LPR1200 V2.0.

Options
For GV ‐ DVR LPR and GV ‐ VMS LPR
GV ‐ IO Box

The GV ‐ IO Box provides 4, 8 or 16 inputs and relay outputs. It supports both DC and AC output

voltages, and provides a USB port for PC connection.

GV ‐ IP LPR Camera 5R

Ideal for parking lot installation, the GV ‐ IP LPR Camera 5R is a 1.3 MP B/W network camera

designed for recognition of reflective license plates on vehicles traveling at 60 km/hr (37 mph) or

less.

GV ‐LPC1100

The GV ‐LPC1100 is a 1.3 MP B/W network camera designed for recognition of reflective license

plates on vehicles traveling at 120 km/hr (75 mph) or less.

GV ‐LPC1200

GV ‐LPC1200 is a 1 MP B/W network camera designed for recognition of reflective license plates on

vehicles traveling at 200 km/h (124.27 mph) or less.

GV ‐LPR1200

GV ‐LPR1200 is a 1 MP B/W network camera designed for recognition of reflective license plates on

vehicles traveling at 200 km/h (124.27 mph) or less. With a built ‐ in LPR processor, the camera is

capable of recognizing the plate numbers and comparing the captured license plates with a

database.

GV ‐LPC2210

GV ‐LPC2210 is a 2 MP color network camera designed for recognition of reflective license plates on

vehicles traveling up at 120 km/h (75 mph) or less.


License Plate Recognition February 7, 2018
-5-
GV ‐LPC2211
GV ‐LPC2211 is a 2 MP color network camera designed for recognition of reflective license plates on

vehicles traveling up at 120 km/h (75 mph) or less.

GV ‐LPC2011

GV ‐LPC2011 is a 2 MP color network camera designed for recognition of reflective license plates on

vehicles traveling up at 60 km/h (37 mph) or less.


For GV ‐ DVR LPR and GV ‐DSP LPR
GV ‐LPR Cam 10A ANPR
Camera

The GV ‐ LPR CAM 10A provides 570 TVL high ‐contrast license plate recognition video to GV ‐DVR LPR

or GV ‐DSP LPR that identifies license plates. The camera features 7 high ‐efficient LEDs for an

illumination range of 7 ~ 12 m (22.96 ~ 39.37 ft).

GV ‐LPR Cam 20A ANPR
Camera

The GV ‐ LPR CAM 20A provides 570 TVL high ‐contrast license plate recognition video to GV ‐DVR LPR

or GV ‐DSP LPR that identifies license plates. The camera features 24 high ‐efficient LEDs for an

illumination range of 15 ~ 25 m (49.21 ~ 82.02 ft).

GV ‐ DSP LPR V3

The GV ‐DSP LPR is a Linux ‐based license plate recognition system built in a small box. Integrating

with a Web server, the GV ‐DSP LPR can host its own Web site and compare captured license plates

with the database downloaded from GV ‐ AS Manager and open a gate barrier when there is a match.
