DS-KAW150-2N
Opis
Zasilacz do stacji bramowej oraz do stacji bramowej "Villa", Napięcie wyjściowe 12 VDC, natężenie wyjściowe 4.2A moc wyjściowa 150W bez opakowania...
Gwarancja: 24 mies.
Karta katalogowa
Tekstowa zawartość karty katalogowej PDF:
DS-KAW150-2N
Power Supply
Available Model
DS-KAW150-2N
Features
Short circuit protection, over load protection, and over power
voltage protection
Natural air cooling
LED power indicator
105 °C long life electrolytic capacitor
5 seconds 300VAC surge voltage input tolerance
Working Temperature: 70 °C
Passes 5G vibration test
Specifications
Parameter Model DS-KAW150-2N
Input voltage 100 VAC to 240 VAC
Output voltage 24 VDC
Output current 6.25 A
Output power 150 W
Noise and ripple < 150 mVpp @ 25 °C
Voltage adjustment
range 23 VDC to 25 VDC
Cooling system Convection
Working temperature
Operating: -10 °C to +70 °C (14 °F to 158 °F)
Storage: -25 °C to +85 °C (-13 °F to 185 °F)
Working humidity < 95% (No Condensation)
Dimension (L x W x D) 178 mm x 97 mm x 38 mm (7.01" x 3.82" x 1.50")
Weight 0.54 kg
Dimensions
20171120
