DS-K1801M
Opis
Czytnik kart Mifare bez klawiatury, obsługuje protokół Wiegand (W26 / W34), pyłoszczelny, IP 65...
Gwarancja: 24 mies.
Karta katalogowa
Tekstowa zawartość karty katalogowej PDF:
1
DS-K1801M
DS-K1801MK
DS-K1801E
DS-K1801EK
PC+ABS material shell
Blue light display button design(DS-K1801EK, and DS-K1801MK)
Equipped with the 32-bit high-speed processor
IP65Standard
Wiegand(w26, w34) protocol
Supports ID card recognition, and ID card number reading(DS-K1801E, and DS-K1801EK)
SupportsMifare card recognition, andMifare card numbereading(DS-K1801M, and DS-K1801MK)
Supportsauthentication methods such as card, and card & password(DS-K1801EK, and
DS-K1801MK)
Supports opening door by swiping card to(DS-K1801E, and DS-K1801M)
Watchdog design
High/low temperature resistant design(-20℃ to +65℃)
Model
Parameters
DS-K1801E DS-K1801EK DS-K1801M DS-K1801MK
Power Supply 12V DC, 0.15A
Inductive Card Reader
MAIN FEATURES
DS-K1801M/MK/E/EK
AVAILABLE MODELS
SPECIFICATIONS
Spec of DS-K1102M/MKInductive Card Reader www.hikvision.com
2
Consumption ≤1W ≤1.5W
Processor 8-bit
Reading card EM card Mifare card
Uplink
communication
interface
Wiegand interface
Reading Range 30~50mm
Audio Alert Beeper
Keypad N/A 12 Keys(0~9,*,#) N/A 12 Keys(0~9,*,#)
LED Indicator Power Indicator; Status LED Indicator
Working
Temperature
-30°C to +65°C
Working Humidity 10% to 90% (Non Condensing)
Dimensions 87(L)mmx87(W)mmx13.3(H)mm
Protection Level IP 65 Standard
