DS-K1108E
Opis
Czytnik kart EM bez klawiatury, obsługuje protokół RS485 i Wiegand (W26 / W34);tamper antysabotażowy, Odporny na kurz, IP 64, montaz do puszek 86 i 120....
Gwarancja: 24 mies.
Uwaga! Produkt wycofany z produkcji!
Karta katalogowa
Tekstowa zawartość karty katalogowej PDF:
1
DS-K1108E DS-K1108EK （ID Card Reading）
DS-K1108M DS-K1108MK （MIFARE Card Reading）
32-bit high-speed processor
Support RS485 and Wiegand(w26, w34) protocol
Build-in ID card reading module (Frequency:125KHz). Supports reading ID card No（DS-K1108E/DS-K1108EK）
Supports Mifare card reading(meet the standards of )ISO 14443-A , including card No.and content reading
Tamper-proof function
Build-in buzzer for status indication
Online upgrading
Accurate data and time display provided by built-in electronic clock and watchdog program to ensure the
basic function of the terminal
Model DS-K1108
Power Supply DC 12V
Power Consumption ≤2W
Processor 32bit
Radio Frequency Standard ISO 14443-A
Card Reader
MAIN FEATURES
DS-K1108
AVAILABLE MODELS
SPECIFICATION
Spec of DS-K1108 Card Reader www.hikvision.com
2
Model DS-K1108
Induction Distance 3-8CM
ID Settings via DIP Switch
Communication Mode RS485/Wiegand（）
Prompt Buzzer
Keypad Physical Key/No Key
LED Indicator Power/Status
Working Temperature -20℃～﹢℃
Working Humidity 10%~90% (No Condensing)
Dimension 123*88*21(mm)
Tamper-Proof Tampering Alarm
Water-Proof Level IP65
Mounting Method Wall Mounting with/without Gang Box
