DS-7208HUHI-F2/N

Rejestrator Turbo-HD Hikvision, 8 wejścia wizyjne BNC (Turbo-HD/AHD/960H/PAL), max. parametry zapisu: 3MP@15kl/s, 1920x1080@25kl/s; kompresja H.264/H.264+; możliwość podłączenia 2 kanałów IP (max. 4MP na kanał), odtwarzanie w trybie pełnoekranowym lub podziale. Dwa strumienie. Wejścia/wyjścia audio: 4/1, 2 interfejs SATA (max. 6TB każdy). Wyjście monitorowe HDMI(4K)/VGA(Full-HD)/CVBS(PAL), 1xRJ-45 (10M/100M/1000M), 1xUSB 2.0, 1xUSB 3.0, 1xRS-485 (PTZ). Wej./wyj. alarmowe: 8/4. Analityka: przekroczenie linii, detekcja intruza; wyszukiwanie VCA. Obudowa 1U, Wymiary: 380x320x48mm. waga około 2kg. Zasilanie 12VDC....

Gwarancja: 36 mies.

Uwaga! Produkt wycofany z produkcji!

Karta katalogowa

Tekstowa zawartość karty katalogowej PDF:

Input and Transmission




Long distance transmission over twisted-pair cable & coax cable

Compression



H.264+ compression improves encoding efficiency by up to 50% and reduces data storage costs


Output



HDMI output at up to

4K (3840 x 2160)

resolution (DS-7208HUHI-F2/N and DS-7216HUHI-F2/N)



CVBS output improves compatibility at the most possibility

Storage



Two

SATA interfaces

(up to 6TB of capacity per HDD)



HDD quota and group management for flexible recording storage



4/8/16-ch synchronous playback



Smart search for efficient playback



Supports the

3
rd

party cloud storage (Dropbox/Google Drive/Microsoft OneDrive)

Smart Function



Supports

multiple VCA(Video Content Analytics) events for both analog and smart IP cameras



VQD(Video Quality Diagnostics)

Network & Ethernet Access



Hik Cloud P2P & HiDDNS (Dynamic Domain Name System) for easy network management



Gigabit Ethernet network interface

(DS-7208HUHI-F2/N and DS-7216HUHI-F2/N)


Features and Functions


DS-7200HUHI-F2/N series
Standard Network Storage





Model

DS-7204HUHI-F2/N

DS-7208HUHI-F2/N

DS-7216HUHI-F2/N



H.264+/H.264


4-ch

8-ch

16-ch

BNC interface (1.0Vp- , supporting coaxitron connection


1080p/25Hz, 1080p/30Hz, 720p/25Hz, 720p/30Hz, 720P/50Hz, 720p/60Hz, 3MP


720p/25Hz, 720p/30Hz

CVBS input

Support

IP video input

2-ch

Up to 4

MP

resolution

Audio
compression

G.711u

Audio input

4-ch, RCA (2.0 Vp- K


CVBS output

Support

HDMI/VGA
output

VGA: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60 Hz

HDMI: 1-ch, 1920 x 1080/60Hz,
1280 x 1024/60Hz,

1280 x
720/60Hz, 1024 x 768/60Hz

HDMI: 1-ch, 4K

(3840 x 2160)/30Hz, 2K

(2560 x 1440)/60Hz,
1920 x 1080/60Hz, 1280 x 1024/60Hz,

1280 x 720/60Hz,
1024 x 768/60Hz

Encoding
resolution

3MP@15fps/1080p/720p/WD1/4CIF/VGA/CIF

Frame rate

Main stream: 25

fps

(P)/30

fps

(N)

Sub-stream:

WD1/4CIF@12fps

(non-real-time);

CIF/QVGA/QCIF

(real time)

Video bitrate

32 Kbps to 10

Mbps

Audio output

1-ch, RCA (Linear, 1 K

Audio bit rate

64 Kbps

Dual-stream

Support

Stream type

Video, Video & Audio

Synchronous
playback

4-ch

8-ch

16-ch

Network
management

Remote
connections

128

Network
protocols

TCP/IP, PPPoE, DHCP, Hik

Cloud P2P, DNS DDNS NTP SADP NFS SCSI UPP , HTTPS,

ONVIF

Hard disk

SATA

2

SATA interfaces

Capacity

Up to 6TB capacity

External
interface

Two-way audio
input

1-ch, RCA (2.0 Vp- K

Network
interface

1, RJ45 10M/100M
self-adaptive Ethernet interface

1, RJ45 10M/100M/1000M

self-adaptive Ethernet interface

USB interface

2

x USB

2.0

Front panel: 1x USB 2.0

Rear panel: 1xUSB 3.0

Serial interface

1; RS-485 serial interface, half-duplex

Alarm in/out

4/1

8/4

16/4

General

Power supply

12 VDC

Consumption

(without HDD)

A

15W

A

20W

A

20W

Working
temperature

-10 ºC to +55 ºC

(14 ºF to

131 ºF)

Working
humidity

10% to

90%

Dimensions

(W x D x H)

380

x 320

x 48

mm (15.0

x

12.6

x

1.9

inch)

Weight

(without HDD)

A

1.5 kg (3.3 lb)

A

2 kg (4.4 lb)

A

2 kg (4.4 lb)

Specifications




Compression
Input
Input
Output
AHD input
HD input
