DS-2CE56H1T-VPITE(6mm)

Kamera 5MP@20fps, 4MP@25fps(P)/30fps(N)(Default), EXIR, 40m IR, Outdoor Vandal Proof Eyeball, ICR, 0.01 Lux/F1.2, 12 VDC/Build-in PoC, Smart IR, DNR, OSD Menu(Up the Coax), IP67, 3.6/6/8/12/16mm Lens...

Gwarancja: 36 mies.

Uwaga! Produkt wycofany z produkcji!

Karta katalogowa

Tekstowa zawartość karty katalogowej PDF:

Key Features
 5 MP high -performance CMOS
 2560 x 1944 resolution
 2.8 mm, 3.6 mm, 6 mm fixed focal lens
 EXIR 2.0, smart IR, up to 20 m IR distance
 OSD menu, DNR, DWDR
 IP67, IK10
 PoC.af
 Up the coax (HIKVISION-C)
DS -2CE56H1T-VPITE
5.0 MP Dome Camera



Camera
Image Sensor 5 MP CMOS image sensor
Resolution 25 60 (H) x 1944 (V)
Min. illumination Color: 0.0 1 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Time
PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
Lens 2.8 mm 3.6 mm, 6 mm fixed focal lens
Horizontal Field of View 94.4 ° (2.8 mm), 72.4 ° (3.6 mm), 48.6 ° (6 mm)
Lens Mount M12
Day & Night IR cut filter
Angle Adjustment Pan : 0° to 355 °; Tilt:0° to 75 °; Rotate: 0° to 355 °
Synchronization Internal synchronization
Frame Rate
2560 x 1944@20fps, 2560 x 1944@12.5fps
2560 x 1440@30fps, 2560 x 1440@25fps (default)
1920 x 1080@30fps, 1920 x 1080@25fps
* Under the PoC mode, 2560 x 1944@12.5fps is not available.
Menu
AGC Support
D/N Mode Auto/Color/BW (Black and White)
White Balance ATW/ MWB
BLC Support
DWDR (Digital Wide Dynamic Range) Support
Language English, Chinese
Functions Brightness, Sharpness, DNR, Mirror, Smart IR
Interface
Video Output 1 HD analog output
General
Operating Conditions -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
Power Supply 12 VDC ±25 %/PoC.af
Power Consumption Max. 4.5 W
Protection Level IP6 7, IK10
Material Metal
IR Range Up to 20 m
Communication Up the coax, Protocol: HIKVISION-C (TVI output)
Dimensions Φ 111 mm x 82.4 mm (Φ 4.4 " x 3.2 ")
Weight Approx. 350 g (0.77 lb.)
Specification



Order Models
DS -2CE56H1T-VPITE
Dimension









Accessory

DS -1259ZJ
Inclined Ceiling Mounting Bracket

DS -1271ZJ-110
Pendant Mounting Bracket

DS -1272ZJ-110B
Wall Mounting Bracket

DS -1275ZJ
Vertical pole mounting Bracket

DS -1280ZJ-DM18
Junction Box


DS -1258ZJ
Wall Mounting Bracket

DS -1H18
Video Balun






030000 1070807 Φ
1
0
0
.
4

m
m

(
4
'
'
)
1
7
.
2

m
m

(
0
.
6
8
"
)
47.2 mm (1.86")
8.7 mm (0.34")
3
2
.
5

m
m

(
1
.
2
8
"
)
38.6 mm (1.52")
Φ 111 mm (4.4'')
8
2
.
4

m
m

(
3
.
2
'
'
)
Φ 79.1 mm (3.1'')
3-5.0 mm (0.2")
